39.11.0.012.0060 (3911 12V DC ELEKTROMEKANİK PLC RÖLE)
Kategori
Marka
Stok Kodu
39.11.0.012.0060
Fiyat
20,09 EUR + KDV
65,37 TL den başlayan taksitlerle!
%42
545,32 TL
940,21 TL
Technical Specifications
Finder 39.11.0.012.0060 technical specifications, attributes, and parameters.
| Physical | |
|---|---|
| Case/Package | Module |
| Contact Material | Silver |
| Mount | DIN Rail |
| Technical | |
| Coil Voltage (AC) | 12 V |
| Coil Voltage (DC) | 12 V |
| Contact Current Rating | 6 A |
| Input Current | 15 mA |
| Max Input Voltage | 12 V |
| Max Operating Temperature | 70 °C |
| Min Operating Temperature | -40 °C |
| Switching Capacity | 1.5 kW |
| Switching Current | 6 A |
| Termination | Screw |
| Throw Configuration | SPDT |
| Turn-Off Delay Time | 6 ms |
| Turn-On Delay Time | 5 ms |
| Dimensions | |
| Depth | 90.7 mm |
| Height | 90.7 mm |
| Length | 87 mm |
| Width | 6.2 mm |
| Compliance | |
| Ratings | IP20 |
| REACH SVHC | No SVHC |
| RoHS | Compliant |
